Raceworks HAL-501 ZF Cherry Red Hall Effect Sensor
$125
Specifications
| Category | Electronics |
|---|---|
| Make | Raceworks |
| Model | Sensors |
| Condition | New |
| Type | Sensors |
| Location | ALTONA MEADOWS, VIC |
| Listing no. | DP-T8RR2BHJ |
Description
Raceworks HAL-501 ZF/Cherry Red Hall Effect gear tooth sensor. Suitable for crank trigger, cam trigger and transmission speed sensing applications. Compatible with all major ECUs and dashes. Specifications. Thread: M12×1. Body: Red Aluminium. Speed Range: Near-zero to 15 kHz. Supply Voltage: 5-24 VDC (30V max). Supply Current: 3mA typical / 6mA max. Output: Open Collector (sinking). Pull-Up Resistor: Required (1kΩ @... Supplied by 12Volt Motorsports, Altona Meadows VIC, motorsport wiring and connector specialists. Price as published on their own site.
